316L 380V Industrial Vacuum Mixer , Cosmetic Cream Mixing Machine PLC Control

316L 380V Cream Industrial Vacuum Mixer with PLC control

Product description

This machine is specialized for liquid mixing (such as detergent, shampoo, laundry detergent, etc), it can also be used to mix different kind of liquid, and liquid with solid in other industries. This mixer is featured with mixing, dispersing, homogenizing, heating, and it is an ideal machine for liquid mixing.

ZJR Vacuum Homogeneity Emulsifier are suit for Cosmetic -face cream, hand cream, sunscreen cream, eyelash to cream, hair gel, lotion, bath shampoo, nail polish.

Pharmaceutical industry- ointments, syrup, nutrition, bio-products, paste of pharmaceutical etc.

Daily use industry-toothpaste, detergents, shoes polish, soap, fragrance etc

Food industry - sauces, jam, chocolate, butter, vegetable proteins, animal proteins etc.

Chemical industry-Painting, pigment, dyes, paints, adhesives detergents etc.

· Capacity:20-30L
· Material: material contact part SS316L, material non-contact part SS304.
· Customized service: to provide and design total solution as per customer URS

Vacuum Emulsifying Machine including:
· Vacuum emulsifying main machine
· Pre-mixing tank for water and oil material
· Vacuum system
· Hydraulic system
· Control system
· Platform made from SS304

Vacuum emulsifying main machine:
· Slow mixer 0-40rpm with PTFE scraper
· Homogenizer 0-3500rpm (rotor and stator can adjust space)
· Heating by steam or electricity
· Pressure: chamber-0.09Mpa to 0.1Mpa, jacket 0.3Mpa for steam (standard type)
· Upper cover lifting by hydraulic
· Safety limit switch for safety operation
· Upper cover connection: Liquid feed inlet with stainless steel pipe filter, solid material inlet, vacuum inlet, compressed air inlet, breaking vacuum inlet, sight glass, CIP cleaning head, discharging port, dustproof respirator.

Water and oil pre-mixing tank
· High shear mixer 960rpm or slow mixer 60rpm
· Heating by steam or electricity
· Pipeline for material transfer to main emulsifying machine

Vacuum system:
· Water ring type vacuum pump or oil type vacuum pump
· Safety valve for protecting the Water ring type vacuum pump

After finish one batch, customer can choose positive pressure or rotor pump for material out.

gel mixing machine

ointment mixer
