High Safety Vacuum Planetary Mixer With Three Layer Stainless Steel Plate Body
Vacuum Planetary Mixer description
Vacuum Planetary Mixer means when the materials are under the vacuum condition, it makes use of the high shear emulsifying to distribute one or several to another continuous phase rapidly and evenly. The materials will be processed in the narrow space between stator and rotor by strong energy of motion produced by the machine effect.
The materials will be dispersed and emulsified instantly and evenly. After reciprocating circulation at high frequency, the fine finished products of stable and high quality without bubbles will be achieved. We use the vacuum pump to remove the bubbles.
The product of CE certification cosmetics vacuum emulsifying mixer, cream homogeneous mixer emulsifying machine mainly applied in such industries as daily chemical care products, biopharmacutical industry, food industry, paint and ink ,nanometer materials, petrochemical Industry, printing and dyeing auxiliaries, pulp & paper, pesticide, ferilizer, plastic & rubber, electronic and electronics, fine chemical industry, etc.
· Capacity:5L-5000L
· Material: material contact part SS316L, material non-contact part SS304.
· Customized service: to provide and design total solution as per customer URS
Vacuum Planetary Mixer Including:
· Vacuum emulsifying main machine
· Pre-mixing tank for water and oil material
· Vacuum system
· Hydraulic system
· Control system
· Platform made from SS304
Water and oil pre-mixing tank
· High shear mixer 960rpm or slow mixer 60rpm
· Heating by steam or electricity
· Pipeline for material transfer to main emulsifying machine
Vacuum system:
· Water ring type vacuum pump or oil type vacuum pump
· Safety valve for protecting the Water ring type vacuum pump
After finish one batch, customer can choose positive pressure or rotor pump for material out.
|
Model
|
Capacity |
Emulsifying motor |
slow mixer motor |
Machine dimension |
Total power(KW) |
|
KW
|
RPM |
KW |
RPM |
LENGTH |
WIDTH |
HEIGHT |
Lifting hight |
| ZRJ-20 |
20L |
2.2 |
1150-3500 |
0.37 |
10-40 |
1800 |
1600 |
1850 |
2700 |
5 |
| ZRJ-50 |
50L |
3 |
1150-3500 |
0.75 |
10-40 |
2700 |
2000 |
2010 |
2700 |
7 |
| ZRJ-100 |
100L |
3 |
1150-3500 |
1.5 |
10-40 |
2920 |
2100 |
2200 |
3000 |
10 |
| ZRJ-150 |
150L |
4 |
1150-3500 |
1.5 |
10-40 |
3110 |
2100 |
2200 |
3100 |
11 |
| ZRJ-200 |
200 |
5.5 |
1150-3500 |
1.5 |
10-40 |
3150 |
2200 |
2200 |
3100 |
12 |
| ZRJ-350 |
350L |
7.5 |
1150-3500 |
2.2 |
10-40 |
3650 |
2650 |
2550 |
3600 |
17 |
| ZRJ-500 |
500L |
7.5 |
1150-3500 |
2.2 |
10-40 |
3950 |
2800 |
2700 |
3950 |
19 |
| ZRJ-1000 |
1000L |
15 |
1150-3500 |
4 |
10-40 |
3900 |
3400 |
3150 |
4550 |
29 |
| ZRJ-1500 |
1500L |
18.5 |
1150-3500 |
7.5 |
10-40 |
4000 |
4100 |
3750 |
5650 |
42 |
| ZRJ-2000 |
2000L |
22 |
1150-3500 |
7.5 |
10-40 |
4850 |
4300 |
3600 |
NO LIFTING |
46 |
